3 - 61

Logic Outputs

Drive Enable activates the motor drive based on the Ramped Reference (MP-46) and
the feedback. The Ramped Reference (MP-46) is the calculated setpoint that is output
from the Acceleration/Deceleration routine.

Dig_Out1 or Dig_Out2 can be used as the Drive Enable output depending on the
setting of CP-10 and CP-11, respectively.

Drive Enable Logic (CP-74) determines which conditions of the Ramped Reference
(MP-46) and feedback will control the Drive Enable output. The factory defaults for
Drive Enable Logic (CP-74) are found in Table 3-49. To modify these default
parameter, refer to Table 3-50. If you are uncertain how to enter a Control Parameters,
review the

Operations: Keypad

section.

Table 3-49 Default Drive Enable Logic Control Parameter

Parameter Name

Parameter Value

CP-10

Alarm 1 Format

CP-11

Alarm 2 Format

CP-74

Drive Enable Logic
