A-2
Analog Input: 0 - 10 VDC Range
33 K
Ω
Input Impedance
12 Bit Resolution
+ 0.1% Linearity Error - Typical
+ 0.05% Drift Error - Typical - Isolated Mode
+ 0.2% Drift Error - Typical - Non-Isolated Mode
Status Outputs: Open-Collector Driver (ULN2003)
(50 VDC max, 200 mA continuous, 500 mA peak)
Optically Isolated
Dig_Out1
Dig_Out2
Speed Command: 0 to 10 VDC
Span Pot Adjustable, 5 to 12 VDC
Optically Isolated
Aux Supply: +5 VDC + 5%
150 mA, Max
non-isolated
Serial Interface: RS485
300 to 9600 Baud
Full parameter access and control
Power Requirements: 115 +15% VAC (model # 3200-1936)
230 +15% VAC (model # 3200-1937)
50/60 Hz
0.1 Amp
Line Loss: 70 mSec ride through
Operating Temperature: 0
°
to 55
°
C Int. Enclosure
0
°
to 40
°
C Ext. Enclosure
Storage Temperature: -25
°
to 70
°
C
Humidity: 0 to 95%, non-condensing
