CONTREX MLP-Trim - Manual (Page 192)

F - 2
Code# Description Displayed Code# Description Displayed
Code# Description User
Record
Code# Description User
Record
Please record the Control Parameters that you have changed from the default value:
Please record what the relevant Monitor Parameters display when the problem occurs:
CP-33 Max RPM Lead
CP-34 Max RPM Feedback
CP-60 Open Loop
CP-61 Direct Enable
CP-62 Inverse Scaling
CP-64 Display Mode Follower
CP-65 Gain
CP-66 Integral
CP-67 Derivative
CP-69 Trim Authority
CP-70 Device Address
CP-71 Baud Rate
CP-72 Character Format
CP-73 Control Mask
CP-74 Drive Enable Logic
CP-75 Offset Null
CP-76 Offset Authority
CP-77 Offset Polarity
CP-79 Setpoint Lockout Mask
CP-84 Analog Input Allocation
CP-85 Analog Input Zero
CP-86 Analog Input Span
CP-01 Master Setpoint 1
CP-02 Master Setpoint 2
CP-03 Follower Setpoint 1
CP-04 Follower Setpoint 2
CP-05 Jog Setpoint
CP-06 Direct Setpoint
CP-08 Minimum Limit
CP-09 Maximum limit
CP-10 Alarm 1 Format
CP-11 Alarm 2 Format
CP-12 Low Alarm
CP-13 High Alarm
CP-14 Ramped Error Alarm
CP-15 Scaled Error Alarm
CP-16 Acceleration Time
CP-17 Deceleration Time
CP-18 Lag Pulse Limit
CP-19 Lead Pulse Limit
CP-20 Master Eng. Units
CP-21 Follower Eng. Units
CP-29 Recovery Multiplier
CP-30 PPR Lead
CP-31 PPR Feedback
MP-53 Control State
MP-54 Logic Inputs-Group A
MP-55 Logic Inputs-Group B
MP-56 Logic Outputs
MP-57 EEPROM Status
MP-58 Serial Comm Error
MP-59 Frequency Overflow
MP-83 Limit Status
MP-87 A/D Input
MP-88 A/D Input Adjusted
MP-99 Software Code Rev
MP-00 Software Part Number
MP-40 Tach
MP-41 Lead Frequency
MP-42 Pulse Error Count
MP-43 Feedback Frequency
MP-44 Deviation (Error)
MP-45 Scaled Reference
MP-46 Ramped Reference
MP-47 Spd Command Output
MP-48 Trim Output
MP-50 Active Scaling Mode
MP-51 Keypad Error
MP-52 Alarm Status
