Kit See Section
Piece
Number
Components Included in Kit
Dust Shields Section 5.1
803129 Trailer Axle Pad & Rotor Shield Kit
803130 Drive Axle Pad & Rotor Shield Kit
802948 Steer Axle Pad Shield Kit
Pad Kit (axle set) Section 5.2 802078
Pad retainer bars (5), set of four pads and holder springs (12), adjuster caps (37), pad retainer
pins (44), washers (45), shear adapters (61).
Spring Clip Kit (box of 25) NA 803151 Spring clips (26)
Shear Adapter (box of 10) NA 802455 Shear adapters (61)
Tappet/Boot Kit (wheel end kit) Section 5.5 802119 Tappet and boot assembly (13), tappet bushing (161), inner seal (22)
Adjuster Cap
(non-wear sensing - box of 10)
NA 802643 Adjuster caps (37)
Guide Pin, Seal and Boot Kit
(wheel end kit)
Section 5.6 803114
Ring (58), inner boot (9), brass bushing (7), guide pin (5), caliper bolt (40), cap (10), guide sleeve
(6), guide pin (4), caliper bolt (39), cap (68)
Guide Pin Grease NA
14525 White (5 grams)
K021964 White (500 grams)
Service Actuator Section 5.4
K028039 Bendix ® Type 14 Universal [Service brake actuator (18/2), actuator hardware]
K028226 Bendix ® Type 16 Universal [Service brake actuator (18/2), actuator hardware]
K028022 Bendix ® Type 18 Universal [Service brake actuator (18/2), actuator hardware]
K028225 Bendix ® Type 20 Universal [Service brake actuator (18/2), actuator hardware]
Spring Brake Actuator Section 5.4
K027557 Bendix ® Type 18/16 Piston Style Truck/Trailer Universal [Spring brake actuator (18/2), actuator hardware]
K025670 Bendix ® Type 18/24 Piston Style Truck/Trailer Universal [Spring brake actuator (18/2), actuator hardware]
K025669 Bendix ® Type 20/24 Piston Style Truck/Trailer Universal [Spring brake actuator (18/2), actuator hardware]
K026451
Bendix ® Type 18/24 Double Diaphragm Style Trailer Universal [Spring brake actuator (18/2), actuator
hardware]
Caliper Kit
(rationalized)
Includes 803114 kit shown above
Section 5.3
K019174 Steer and Drive Axle "A" [Caliper kit (1)]
K019175 Steer and Drive Axle "B" [Caliper kit (1)]
K019180 Trailer Axle "A" [Caliper kit (1)]
K019181 Trailer Axle "B" [Caliper kit (1)]
Carrier Kit
Sections 5.3
& 5.6
K051853
Steer and Drive Axle, Axial (Ring (58), inner boot(9), caliper bolt (40), cap (10), shear adapter
(61), adjuster caps (37), ADB22X carrier complete (1), caliper bolt (39), cap (68).
K043288
Trailer Axle, Axial (Ring (58), inner boot(9), caliper bolt (40), cap (10), shear adapter (61), adjuster
caps (37), ADB22X carrier complete (1), caliper bolt (39), cap (68).
K056559
Steer and Drive Axle, Vertical (Ring (58), inner boot(9), caliper bolt (40), cap (10), shear adapter
(61), adjuster caps (37), ADB22X-V carrier complete (1), caliper bolt (39), cap (68).
Caliper/Carrier Kit
802090 Steer and Drive Axial “A” (1 + 2A)
809091 Steer and Drive Axial “B” (1 + 2A)
802984 Trailer Axial “A” (1 + 2A)
802985 Trailer Axial “B” (1 + 2A)
K021299 Steer and Drive Vertical “A” (1 + 2B)
K021300 Steer and Drive Vertical “B” (1 + 2B)
Hubs Section 5.7
K020505 Splined Disc ® Brake - Aluminum - FF Steer, LMS Bearing Package (Hub)
803134 Splined Disc ® Brake - Aluminum - FL Steer, LMS Bearing Package (Hub)
802847 Splined Disc ® Brake - Aluminum - R Drive, LMS Bearing Package (Hub)
K020514 Splined Disc ® Brake - Aluminum - FF Steer, Standard Bearing Package* (Hub)
803138 Splined Disc ® Brake - Aluminum - FL Steer, Standard Bearing Package* (Hub)
802859 Splined Disc ® Brake - Aluminum - R Drive, Standard Bearing Package* (Hub)
K045298 Splined Disc ® - Aluminum - "TN" Trailer, Standard bearing package* (Hub)
K045297 Splined Disc ® - Aluminum - "TP" Trailer, Standard bearing package* (Hub)
See hub
supplier for
these items
U-shaped - Iron/Aluminum, LMS/Standard Bearing Packages
Flat - Iron/Aluminum, LMS/Standard Bearing Packages
Splined Disc ® Rotor Attaching Kit Section 5.7 K037766 All Splined Disc ® Rotor Applications (Splined Disc Rotor hardware kit SD-1, -2, and -3)
Rotor Section 5.7
802081 138mm U-shaped (Rotor, fasteners)
802082 150mm U-shaped (Rotor, fasteners)
802083 Severe Duty Splined Disc Kit (Splined Disc Rotor (SD), and hardware kit SD-1, -2, and -3)
802569 Heavy Duty Splined Disc Kit (Splined Disc Rotor, and hardware kit SD-1, -2, and -3)
* Universal Replacement with standard bearing configuration and long studs. Contact 1-800-AIR-BRAKE if identification assistance is required.
5.0 MAINTENANCE KITS
Below is a list of some of the available kits. See Figure 30 for an exploded view showing the components listed.
TABLE 2 - MAINTENANCE KITS
