Clear-Com ICS-2003 - Manual (Page 58)

Clear-Com Communication Systems
ICS-2003 Intercom Panel Instruction Manual
3 - 1 8
Diodes and Transistors
Integrated Circuits
68.1K Ω 1/10 SMD 1% 411565 R63
100K Ω 1/10 SMD 1% 411581 R13 R31
150K Ω 1/10 SMD 1% 411598 R92 R105
R112 R117
R130
1.0M Ω 1/10 SMD 5% 411677 R84
1.2M Ω 1/10 SMD 5% 411685 R80
2.2M Ω 1/10 SMD 5% 411710 R76
Device Description Part # Designator
Diode BAV70 Dual Diode
Com Cath 481019 D1 D4
Diode BAV99 Dual Diode
Series SMD 481033 D2 D3 D5 D6 D7
D8 D9 D10 D11
D12
Transistor 2222A NPN 40V
600ma SMD 481026 Q7 Q8 Q9
Transistor 2907A PNP 60V
600ma SMD 481027 Q1
Transistor J175 P-Ch JFET
SMD 481056 Q6
Transistor MPSA14 NPN 30V
300ma SMD 481038 Q4 Q5
Device Description Part # Designator
Analog IC 555 CMOS TIMER
SMD 481051 IC16
Analog IC LM384 POWER 4W
OP AMP 480012 IC21
Value Power Type Tol. Part # Designator
