Hydrotech 6200 SXT Automatic Meter Initiated Water Softener - Manual (Page 30)

29
Bypass Valve Assembly & Yokes (Plastic)
2310 Safety Brine Valve
Item no. Quantity Part no. Description
1 2 13305 O-ring, -119
2 2 13255 Clip, Mounting
3 2 13314 Screw, Hex Washer Head, 8-18 x 5/8
4A 1 18706 Yoke, Plastic, 1” NPT
18706-02 Yoke, Plastic, 3/4” NPT
4B 1 13708 Yoke, Brass, 3/4” NPT
13708NP Yoke, 3/4” NPT Nickel Plated
13398 Yoke, Brass, 1” NPT
13398NP Yoke, 1” NPT Nickel Plated
40636 Yoke, 1 1/4” NPT
40636-49 Yoke, 1 1/4” Sweat
Item no. Quantity Part no. Description
1 1 19645 Body, Safety Brine Valve, 2310
2 1 19803 Safety Brine Valve Assembly
3 1 19804 Screw, Socket Hd, Set, 10-24 X .75
4 1 19805 Poppet Assembly, SBV w/O-ring
5 1 19652-01 3RSSHW $VV\, 6%9 Z/2-ULQJ
6 1 19649 Flow Dispenser
7 1 11183 O-ring, -017
8 1 19647 Elbow, Safety Brine Valve
9 2 19625 Nut Assembly, 3/8” Plastic
10 1 18312 Retainer, Drain
11 1 60014 Safety Brine Valve Assembly, 2310
12 2 10150 Grommet, .30 Diameter
13 1 60068-30 Float Assembly, 2310, w/30” Rod
14 1 60002-34 Air Check, #500, 34” Long
