Hydra-Tech S12M User Manual
Page 2
Model S12M Overall Dimensions
S12M Typical Performance
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
:
Curves are based on pumping water at 60°F. For performance curves other than shown above, consult factory.
21" (53 cm)
17"
41"
(43 cm)
(104 cm)
Optional
Flange
19" O.D.
12 3/4" Pipe O.D.
18 3/4"
(48 cm)
Optional
Flange
A) Typical Performance with
HT35 Power Unit
Input hydraulic flow:
20 GPM @ 2500 PSI
B) Typical Performance with
HT60 Power Unit
Input hydraulic flow:
26 GPM @ 2800 PSI
0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000
55
50
45
40
35
30
25
20
15
10
5
5
10
15
U.S.G.P.M.
Cu. Mtr./Hr.
Feet
Meters
200 400 600 800 1000
CAPACITY
TOTAL HEAD
40
35
30
25
20
15
10
5
NPSHR (Ft)
A
B
