Hydra-Tech S3SCR User Manual
3” hydraulic submersible, Centrifugal screw pump, Features

MODEL S3SCR
3” (75 mm) Discharge
3” HYDRAULIC SUBMERSIBLE
CENTRIFUGAL SCREW PUMP
The S3SCR is ideal for pumping high
viscosity liquids such as crude oils, latex,
molasses and refinery wastes using a positive
displacement screw. When pumping lighter
materials, the impeller acts as a centrifugal
type providing high capacity. Typical uses
include oil skimmers and cargo pumping.
FEATURES
•
Unique Centrifugal Screw Impeller for
pumping of liquids with viscosities to
25,000 CST
•
Small Overall Size allows for use in
confined spaces
•
Oil Lubricated Seals (can run dry)
•
Can be used inline as a booster pump
•
Safe Hydraulic Drive can be used where
electric power is hazardous or impractical
•
Optional ceramic coated case for abrasion
resistance
•
Operates with our HT10 to HT25 power
units or other hydraulic power sources
capable of flows of 6 - 11 GPM
B0109
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
WEIGHT:.............................................. 43 lbs. (20 kg)
HEIGHT:............................................. 16 1/2" (42 cm)
WIDTH (@ widest point):.................. 9 1/4" (23.5 cm)
DISCHARGE:............................................ 3" NPT (F)
INLET FLANGE:.................................... 3" 125# ASA
SOLIDS HANDLING:...........................1 1/2" (38 mm)
HOSE PORTS:....................................... 1/2" JIC (M)
PUMP BODY:........................ Heat Treated Aluminum
IMPELLER / SCREW:........ CD4MCU Stainless Steel
SUCTION CASE:*................. Heat Treated Aluminum
ELASTOMERS:...................................... Buna N (Std)
HYDRAULIC OIL:...... 214-320 s.s.u. @ 100°F (64°C)
INPUT FLOW:....................... Max. 11 GPM (42 LPM)
OPERATING PRESSURE:. Max. 3000 PSI (204 Bar)
POWER SOURCE:.
Any Open Center Hydraulic System
* Optional ceramic coating available
SPECIFICATIONS
Specifications are subject to change without notice
