Hydra-Tech S4TAL-2 User Manual
4” hydraulic submersible solids handling pump, Features, Models s4t-2

MODELS
S4T-2
(Ductile Iron Body)
S4TAL-2
(Aluminum Body)
4” (100 mm) Discharge
4” HYDRAULIC SUBMERSIBLE
SOLIDS HANDLING PUMP
The S4T-2 and S4TAL-2 solids
handling pumps are designed to be
durable and lightweight yet able to
pump more abrasive liquids. These
pumps incorporate a larger silicon
carbide mechanical seal and
replaceable wear plates. The pump
body can be lined with wear resistant
ceramic or polyurethane coatings for
even more durability.
FEATURES
•
2-Vane Channel Impeller
(will pass 3" (75 mm) semi-solids)
•
Variable Speed hydraulic drive
•
Replaceable wear plates
•
Silicon Carbide mechanical seal
•
Can be bolted directly to a tank or truck
•
Dependable gear type hydraulic motor
•
Operates with our HT20 to HT35 power
units or other hydraulic power sources
capable of flows of 12 - 21 GPM
C0413
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
WEIGHT:
(Ductile Iron Body)
................. 108 lbs. (49 kg)
(Aluminum Body)
................... 82 lbs. (37 kg)
HEIGHT:................................................... 19” (48 cm)
WIDTH (@ widest point):.................... 19-1/2" (50 cm)
DISCHARGE:.............................................. 4" NPT(F)
INLET FLANGE:................................... 4", 125# ASA
SOLIDS HANDLING:................................ 3" (75 mm)
HOSE PORTS:.............. (Pressure) 7/8-14 (-10) SAE
(Return)1-1/6-12 (-12) SAE
PUMP BODY:
(S4T-2)
................................ Ductile Iron
(S4TAL-2)
.............................. Aluminum
IMPELLER:............................................... Ductile Iron
WEAR PLATES:................................. Stainless Steel
SHAFT SEAL:.................................... Silicon Carbide
ELASTOMERS:..................................... Buna N (Std)
HYDRAULIC OIL:..... 214-320 s.s.u. @ 100°F (64°C)
INPUT FLOW:....................... Max. 21 GPM (79 LPM)
OPERATING PRESSURE:. Max. 2600 PSI (177 Bar)
POWER SOURCE:..
Any Open Center Hydraulic System
SPECIFICATIONS
Specifications are subject to change without notice
