Hydra-Tech S4TLPAL User Manual
4” hydraulic submersible trash pump, Features, Models s4tlp

MODELS
S4TLP
(Ductile Iron Body)
S4TLPAL
(Aluminum Body)
4” (100 mm) Discharge
4” HYDRAULIC SUBMERSIBLE
TRASH PUMP
The S4TLP trash pump is designed to
fit into tighter spaces and can be used
for tank truck mounting for direct
loading/offloading using on-board
hydraulics. It is well suited for operating
with smaller hydraulic tool power units.
Your preference of durable ductile iron
or lightweight aluminum body makes
this pump an all around choice.
FEATURES
•
2-Vane Channel Impeller
(will pass 3" (75 mm) semi-solids)
•
Variable Speed hydraulic drive
•
Wide Range of performance
•
Can be bolted directly to a tank or truck.
•
Safe Hydraulic Drive can be used where
electric power is hazardous or impractical
•
Dependable gear type hydraulic motor
•
Operates with our HT10 to HT20 power
units or other hydraulic power sources
capable of flows of 5-10 GPM
A1110
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
WEIGHT: S4TLP................................ 107 lbs. (48 kg)
S4TLPAL ............................ 68 lbs. (31 kg)
HEIGHT:............................................. 13-3/4” (40 cm)
WIDTH (@ widest point):.................... 19-1/2" (50 cm)
DISCHARGE:.............................................. 4" NPT(F)
INLET FLANGE:................................... 4", 125# ASA
SOLIDS HANDLING:................................ 3" (75 mm)
HOSE PORTS:.................... 7/8-14 UNF (-10) SAE(F)
PUMP BODY: S4TLP................................ Ductile Iron
S4TLPAL............................. Aluminum
IMPELLER:............................................... Ductile Iron
SHAFT SEAL:...................... Grease Lube Double Lip
ELASTOMERS:..................................... Buna N (Std)
HYDRAULIC OIL:..... 214-320 s.s.u. @ 100°F (64°C)
INPUT FLOW:....................... Max. 10 GPM (38 LPM)
OPERATING PRESSURE:. Max. 2800 PSI (190 Bar)
POWER SOURCE:..
Any Open Center Hydraulic System
SPECIFICATIONS
Specifications are subject to change without notice
