Hydra-Tech S2TCAL-2 User Manual
2” hydraulic submersible utility pump, Features, Model s2tc-2

MODEL S2TC-2
(Ductile Iron Body)
MODEL S2TCAL-2
(Aluminum Body)
2” (50 mm) Discharge
2” HYDRAULIC SUBMERSIBLE
UTILITY PUMP
The S2TC-2 is a very portable and
versatile all purpose utility pump. The
two channel impeller handles solids and
offers excellent overall performance.
This pump is available with your choice
of water or solids handling strainers.
FEATURES
•
Efficient Two Channel Impeller will pass
1" (25mm) semi-solids
•
Rugged and Reliable gerotor motor
•
Variable Speed hydraulic drive
•
Small Overall Size makes this pump very
versatile
•
Can be bolted directly into a pipeline
•
Safe Hydraulic Drive can be used where
electric power is hazardous or impractical
•
Operates with our HT6 and HT7 power
units or other hydraulic power sources
capable of flows to 5 GPM
D0109
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
WEIGHT: S2TC-2........................................ 25 lbs. (11 kg)
S2TCAL-2................................... 17 lbs. (7.7 kg)
HEIGHT:............................................................. 13" (33 cm)
WIDTH (@ widest point):............................... 9 3/8" (24 cm)
DISCHARGE:....................................................... 2" NPT(F)
INLET FLANGE:................................................. 1 1/2" 125#
SOLIDS HANDLING:........................................... 1" (25 mm)
HOSE PORTS:................................... 3/8" SAE (-6) 'O' Ring
PUMP BODY: S2TC-2...................................... Ductile Iron
S2TCAL-2..................................... Aluminum
IMPELLER:......................................................... Ductile Iron
SHAFT:.......................................... Heat Treated Steel Alloy
SHAFT SEAL:.................................... Carbon/Ceramic (Std)
ELASTOMERS:................................................ Buna N (Std)
HYDRAULIC OIL:................ 214-320 s.s.u. @ 100°F (64°C)
INPUT FLOW:.................................. Max. 5 GPM (19 LPM)
OPERATING PRESSURE:.. Cont. Max: 2000 PSI (136 Bar)
Int. Max: 2500 PSI (172 Bar)
POWER SOURCE:...... Any Open Center Hydraulic System
SPECIFICATIONS
Specifications are subject to change without notice
