Hydra-Tech S10T User Manual
10” hydraulic submersible, Vortex flow trash pump, Features
MODEL S10T
10” (250 mm) Discharge
10” HYDRAULIC SUBMERSIBLE
VORTEX FLOW TRASH PUMP
The S10T is designed to handle large
solids and stringy material with its fully
recessed Vortex impeller. Typical
applications include sludge lagoons,
sewage digester tanks and fish farms.
FEATURES
C0413
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
:
WEIGHT:..................................................... 745 lbs. (346 kg)
HEIGHT:............................................................ 45" (114 cm)
WIDTH (@ widest point):........................... 42 1/2" (108 cm)
DISCHARGE:...................................... 10" 125# ASA Flange
INLET:.................................................. 10" 125# ASA Flange
SOLIDS HANDLING:
(spherical semi-solids)
................ 8" (20 cm)
HOSE PORTS:.................... 1 1/4" or 1 1/2" NPT(F) or SAE
PUMP BODY:..................................................... Ductile Iron
IMPELLER:......................................................... Ductile Iron
WEAR RING and PLATE:........................... ASTM A36 Steel
SHAFT:........................................... 17-4 PH Stainless Steel
SHAFT SEAL:............................................... Silicon Carbide
ELASTOMERS:................................................ Buna N (Std)
HYDRAULIC OIL:................ 214-320 s.s.u. @ 100°F (64°C)
INPUT FLOW:................................ Max 70 GPM (265 LPM)
OPERATING PRESSURE:............. Max 2800 PSI (190 Bar)
POWER SOURCE:....... Any Open Center Hydraulic System
SPECIFICATIONS
Specifications are subject to change without notice
•
Recessed Vortex Impeller
(will pass 8" semi-solids)
•
Variable Speed hydraulic drive provides
a wide range of performance
•
Oil Lubricated Seals (can run dry)
•
High Efficiency Balanced Vane
hydraulic motor
•
Can be bolted directly into a pipeline or
used as a booster pump
•
Safe Hydraulic Drive can be used where
electric power is hazardous or
impractical
•
Operates with our HT100 to HT150
power units or other hydraulic power
sources capable of flows of 50 - 70 GPM
