Hydra-Tech S3CSL User Manual
3” hydraulic submersible, Sand / slurry pump, Features

MODEL S3CSL
3” (75 mm) Discharge
3” HYDRAULIC SUBMERSIBLE
SAND / SLURRY PUMP
with AGITATOR
The S3CSL pump is designed to use in
applications requiring settled solids to be put
into suspension and pumped with the discharge
water. Primary applications include de-silting
ponds, lakes and streams. Other jobs may
include filling sand bags to prevent beach
erosion, tank and digester cleaning or pumping
residue from rail tank cars or barges.
FEATURES
•
Hardened Alloy Wear Parts
•
Built-in Agitator for stirring up solids
•
Oil Lubricated Seals (can run dry)
•
Variable Speed hydraulic drive
•
Small Size allows pump to fit through a
17 inch opening
•
Safe Hydraulic Drive can be used where
electric power is hazardous or impractical
•
Dependable gear type hydraulic motor
•
Operates with our HT10 to HT20 power
units or other hydraulic power sources
capable of flows to 10 GPM
B0109
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
WEIGHT:..........................................231 lbs. (105 kg)
HEIGHT:..............................................30 1/4" (77 cm)
WIDTH (@ widest point):....................16 1/4" (41 cm)
DISCHARGE:..................................................3" NPT
SOLIDS HANDLING:..........................1 1/2" (38 mm)
HOSE PORTS:..........................1/2" and 3/4" NPT (F)
VOLUTE*:................................ Hardened Ductile Iron
IMPELLER:................................... High Chrome Alloy
WEAR PLATE............................... High Chrome Alloy
AGITATOR:...................................High Chrome Alloy
SHAFT:.........................................304 Stainless Steel
SHAFT SEALS: (upper)....................Carbon/Ceramic
(Lower)......................Silicon Carbide
HYDRAULIC OIL:.......214-320 s.s.u. @ 100°F (64°C)
INPUT FLOW:.........................Max 10 GPM (38 LPM)
OPERATING PRESSURE:....Max 3000 PSI (204 Bar)
POWER SOURCE:..
Any Open Center Hydraulic System
* Optional NI-Hard volute available for highly abrasive applications
SPECIFICATIONS
Specifications are subject to change without notice
