MODEL S6P
6” (150 mm) Discharge
6” HYDRAULIC SUBMERSIBLE
AXIAL FLOW HIGH VOLUME PUMP
The S6P is a lightweight axial flow pump designed for
pumping high volumes of water at relatively low
heads. The propeller design allows this pump to
driven by small hydraulic power sources such as small
tractors, backhoes or our 10 to 15 HP power units.
This pump is great for lake draining, tank filling, flood
irrigation, arial firefighting and cofferdam de-watering.
FEATURES
•
High Volume Axial Propeller design
•
Very Light Weight allows for one man
set-up
•
Small Overall Size allows for use in very
tight spaces
•
Variable Speed hydraulic drive
•
Oil Lubricated Seals (can run dry)
•
Dependable gear type hydraulic motor
•
Safe Hydraulic Drive can be used where
electric power is hazardous or
impractical
•
Operates with our HT10 to HT15 power
units or other hydraulic power sources
capable of flows of 5 - 7 GPM
D0413
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
:
WEIGHT:.............................................. 40 lbs. (18 kg)
HEIGHT:................................................... 16" (41 cm)
DIAMETER (@ widest point):..............11 3/4" (30 cm)
DISCHARGE:.............................................. 6" NPT(F)
SOLIDS HANDLING:................................. 3/4" (2 cm)
HOSE PORTS:..............................................1/2" NPT
PUMP BODY:........................ Heat Treated Aluminum
PROPELLER:........................................... Ductile Iron
WEAR RING............................................. Ductile Iron
SHAFT:................................................... Plated Steel
SHAFT SEAL:.......................... Carbon/Ceramic (Std)
ELASTOMERS:...................................... Buna N (Std)
HYDRAULIC OIL:...... 214-320 s.s.u. @ 100°F (64°C)
INPUT FLOW:......................... Max. 7 GPM (26 LPM)
INPUT PRESSURE:........
Max. Cont. 2500 PSI (170 Bar)
POWER SOURCE:
... Any Open Center Hydraulic System
SPECIFICATIONS
Specifications are subject to change without notice
