Hydra-Tech S6250 User Manual
10” hydraulic submersible, Features, Model s6250
MODEL S6250
10” (250 mm) Discharge
10” HYDRAULIC SUBMERSIBLE
HIGH PERFORMANCE,
SOLIDS HANDLING PUMP
The S6250 is a Solids Handling Effluent
Pump for use on jobs such as Waste
Treatment, Sewer By-Pass, Barge Transfer,
Municipal Lift Stations and Tank Pumping.
FEATURES
C0413
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
:
WEIGHT:..................................................... 739 lbs. (336 kg)
HEIGHT:............................................................ 43" (109 cm)
WIDTH (@ widest point):.................................... 32" (81 cm)
DISCHARGE:..................................... 10", 125# ASA Flange
INLET:................................................ 10", 125# ASA Flange
SOLIDS HANDLING:........................................ 4" (100 mm)
HOSE PORTS:......1-1/4" Code 61 Flange or 1-1/2" NPT (F)
PUMP BODY:...................................................... Ductile Iron
IMPELLER:.......................................................... Ductile Iron
WEAR RING........................................................ Ductile Iron
SHAFT:.............................................17-4 PH Stainless Steel
SHAFT SEAL:............................................... Silicon Carbide
ELASTOMERS:................................................ Buna N (Std)
HYDRAULIC OIL:................ 214-320 s.s.u. @ 100°F (64°C)
INPUT FLOW:................................. Max 90 GPM (340 LPM)
OPERATING PRESSURE:............. Max 2500 PSI (170 Bar)
POWER SOURCE:....... Any Open Center Hydraulic System
SPECIFICATIONS
Specifications are subject to change without notice
•
Balanced High Efficiency Two Vane
Closed Channel Impeller
•
Will pass 4" (100 mm) semi-solids
•
Variable Speed hydraulic drive provides
a wide range of performance
•
Oil Lubricated Seals (can run dry)
•
High Efficiency Balanced Vane
hydraulic motor
•
Can be bolted directly into a pipeline or
used as a booster pump
•
Safe Hydraulic Drive can be used where
electric power is hazardous or
impractical
•
Operates with our HT100 to HT200
power units or other hydraulic power
sources capable of flows of 50 - 90 GPM
