Hydra-Tech S3CML User Manual
3” hydraulic submersible high performance pump, Features, Model s3cml
MODEL S3CML
3” x 2” (75 mm x 50 mm)
3” HYDRAULIC SUBMERSIBLE
HIGH PERFORMANCE PUMP
The S3CML is highly efficient water pump
for use where small size, light weight, yet
high performance pumping is required.
Applications include portable firefighting,
mine and deepwell de-watering, barge and
ship tank stripping, irrigation, piling and
dock jetting, and many other high head
applications.
FEATURES
C0109
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
:
WEIGHT:............................................. 45 lbs. (21 kg)
HEIGHT:............................................. 16 5/8" (42 cm)
WIDTH(@ widest point):..................... 11 3/4" (30 cm)
DISCHARGE:............................................. 2" NPT(F)
INLET FLANGE:.................................... 3" 125# ASA
HOSE PORTS:................... 3/4" SAE (-12) or NPT(F)
PUMP BODY:....................... Heat Treated Aluminum
IMPELLER:..................................................... Bronze
WEAR RINGS:................................................ Bronze
SHAFT:............................................... Stainless Steel
SHAFT SEAL:........................ Carbon / Ceramic (Std)
ELASTOMERS:..................................... Buna N (Std)
HYDRAULIC OIL:............SAE 10W or 20W Type AW
also:......Dexron ATF or Biodegradable Oil
INPUT FLOW:...................... Max. 16 GPM (60 LPM)
OPERATING PRESSURE:....Max 3500 PSI (238 Bar)
POWER SOURCE:
Any Open Center Hydraulic System
SPECIFICATIONS
Specifications are subject to change without notice
•
Compact, Powerful pump for High-Head
applications
•
Will pass through a 12 in. diameter deck
opening or deepwell casing
•
Oil Lubricated Seals (can run dry)
•
Variable Speed hydraulic drive
•
Wide Range of performance
•
Can be bolted directly into a pipeline
•
Safe Hydraulic Drive can be used where
electric power is hazardous or impractical
•
High Efficiency piston hydraulic motor
•
Operates with our HT15 to HT35 power
units or other hydraulic power sources with
flows to 10 -16 GPM
