Hydra-Tech S6CSL User Manual
6” hydraulic submersible, Sand / slurry pump, Features

MODEL S6CSL
6” (150 mm) Discharge
6” HYDRAULIC SUBMERSIBLE
SAND / SLURRY PUMP
with AGITATOR
The S6CSL pump is designed to use in
applications requiring settled solids to be
put into suspension and pumped with the
discharge water. Primary applications
include de-silting waterways. Other jobs
may include filling sand bags to prevent
beach erosion, tank and digester cleaning
or pumping sediment from caissons.
FEATURES
C0413
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
SPECIFICATIONS
Specifications are subject to change without notice
•
Hardened Alloy Wear Parts
•
Built-in Agitator for stirring up solids
•
Oil Lubricated Seals (can run dry)
•
Variable Speed hydraulic drive
•
Small Size allows pump to fit through a
22 inch opening
•
Safe Hydraulic Drive can be used where
electric power is hazardous or impractical
•
Dependable gear type hydraulic motor
•
Operates with our HT50 to HT75 power
units or other hydraulic power sources
capable of flows to 28 GPM
WEIGHT:.......................................... 528 lbs. (240 kg)
HEIGHT:................................................... 39" (99 cm)
WIDTH (@ widest point):................... 21 1/4" (54 cm)
DISCHARGE:................................................. 6" NPT
SOLIDS HANDLING:......................... 1 1/2" (38 mm)
HOSE PORTS:...........................................1" NPT (F)
VOLUTE*:................................ Hardened Ductile Iron
IMPELLER:................................... High Chrome Alloy
WEAR PLATE............................... High Chrome Alloy
AGITATOR:.................................. High Chrome Alloy
SHAFT:.............................................. Stainless Steel
SHAFT SEALS: (upper)..................... Silicon Carbide
(Lower)..................... Silicon Carbide
HYDRAULIC OIL:...... 214-320 s.s.u. @ 100°F (64°C)
INPUT FLOW:...................... Max 28 GPM (106 LPM)
OPERATING PRESSURE:... Max 2800 PSI (190 Bar)
POWER SOURCE:..
Any Open Center Hydraulic System
* Optional NI-Hard volute available for highly abrasive applications
