Hydra-Tech S4CSL - Manual (Page 2)

Model S4CSL Overall Dimensions
S4CSL Typical Performance
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
: www.hydra-tech.com E-Mail : [email protected]
Curves are based on pumping water at 60°F. For performance curves other than shown above, consult factory.
31"
16 1/4"
(41cm)
(79c
m)
14"
16
1/
4"
(36cm)
(41c
m)
HYDRAULIC INPUT:
(A) 10 GPM @ 850 - 1250 PSI
(B) 12 GPM @ 900 - 1500 PSI
(C)* 14 - 15.6 GPM @ 1700 - 2100 PSI
(D) 17 GPM @ 1700 - 2750 PSI
* Typical Performance with
HT25 Power Unit
0
135
120
105
90
75
60
45
30
15
15
30
41
U.S.G.P.M.
Liters/Minute
Feet Me
te
rs
450
A
B
C
D
CAPACITY
T
O
T
A
L
H
EA
D
75 150 225 300 375 450 525 600 675 750
900 1350 1800 2250 2700
