Hydra-Tech S6CSL - Manual (Page 2)

Model S6CSL Overall Dimensions
S6CSL Typical Performance
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
: www.hydra-tech.com E-Mail : [email protected]
Curves are based on pumping water at 60°F. For performance curves other than shown above, consult factory.
39"
(99c
m)
18"
21-1/
4"
(46cm)
(54c
m)
Pressure Return
Hydra-Tech Pumps
HYDRAULIC INPUT:
(A) 15 GPM @ 700 - 950 PSI
(B) 20 GPM @ 1050 - 1500 PSI
(C) 25 GPM @ 1650 - 2150 PSI
(D) * 27 GPM @ 1950 - 2550 PSI
* Typical Performance with
HT60DJV Power Unit
