Hydra-Tech S2TAL-2 - Manual (Page 2)

Model S2T-2 Overall Dimensions
S2T-2 Typical Performance
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
: www.hydra-tech.com E-Mail : [email protected]
Curves are based on pumping water at 60°F. For performance curves other than shown above, consult factory.
HYDRAULIC INPUT:
(A) 2 GPM @ 700-1300 PSI
(B) 3 GPM @ 1100-2050 PSI *
(C) 4 GPM @ 1600-2400 PSI
(D) 4.3 - 5 GPM @ 2150-2500 PSI**
*Typical perf. with HT6 power unit
**Typical perf. with HT13 power unit
0
105
90
75
60
45
30
15
15
30
U.S.G.P.M.
Liters/Minute
Feet Meters
150
A
B
C
D
CAPACITY
TOTAL HEAD
50 25 75 100 125 150 175 200 225
300 450 600 750
HTMA Hose Couplings
Water Strainer
(Optional)
6"
13"
1 1/2"
2 1/2"
(33 cm)
(3.8 cm)
(6.4 cm)
(15.2 cm)
(23.8 cm)
9 3/8"
12"
2" Female Pipe Threads
(30 cm)
