Model S6105 Overall Dimensions
S6105 Typical Performance
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
: www.hydra-tech.com E-Mail : [email protected]
Curves are based on pumping water at 60°F. For performance curves other than shown above, consult factory.
400
360
320
280
240
200
160
120
80
40
U.S.G.P.M.
Fe
et
Meters
40
80
120
TOTAL D
YNAMIC HE
AD
VOLUME
80
0
Cu. Mtr./Hr.
200 400 600 800 1000 1600 2000 1800 1400 1200
160 320 240 400
A
B
HYDRAULIC INPUT:
(A)40-50 GPM @ 2500 PSI Max.
!!!Typical Performance w/HT100 P/U
(B)60-70 GPM @ 2500 PSI Max.
!!!Typical Performance w/HT150 P/U
25"
4",150 lb. ANSI Flange
36"
(9
1
c
m)
(64 cm)
21"
6"
(53 cm)
(1
5
c
m)
