Model S4THL Overall Dimensions
S4THL Typical Performance
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
:
Curves are based on pumping water at 60°F. For performance curves other than shown above, consult factory.
(65 cm)
34
1/
2"
25 1/2"
(88
cm)
16"
(41
cm)
0
200
180
160
140
120
100
80
60
40
20
20
40
60
U.S.G.P.M.
Liters/Minute
Feet
Me
te
rs
600
CAPACITY
T
O
T
A
L
H
EA
D
30
50
10
100
200
300
400
500
600
700
800
900 1000
1100
1200
1800
2400
3000
3600
4200
220
67
A
B
C
HYDRAULIC INPUT:
(A) 18 GPM @ 1050 - 2800 PSI
(B) 19 - 26 GPM @ 1800-2850 PSI*
(C) 21 - 30 GPM @ 3000 PSI**
*Typical perf. with HT60 power unit
**Maximum performance
