Hydra-Tech S4TAL-2 - Manual (Page 2)

Model S4T-2 Overall Dimensions
S4T-2 Typical Performance
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
: www.hydra-tech.com E-Mail : [email protected]
Curves are based on pumping water at 60°F. For performance curves other than shown above, consult factory.
4" NPT (F)
19"
(48
cm)
19 1/2" (50 cm)
15"
(38
cm)
Return Port
1-1/16-12 (SAE -12)
Pressure Port
7/8-14 (SAE -10)
0 100 200 300 400 500 600 700 800
140
120
100
80
60
40
20
20
40
U.S.G.P.M.
Liters/Minute
Feet Meters
600 1200 1800 2400 3000
CAPACITY
TO
T
A
L
HEAD
10
30
A
B
C
D
Hydraulic Input:
A) 12 GPM @ 400 - 1000 PSI
B) 15 GPM @ 500 - 1500 PSI
C) 18 GPM @ 850 - 2000 PSI
D) 21 GPM @ 1050 - 2550 PSI
