Model S6150 Overall Dimensions
S6150 Typical Performance
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
: www.hydra-tech.com E-Mail : [email protected]
Curves are based on pumping water at 60°F. For performance curves other than shown above, consult factory.
21"
6"
(53cm)
(15cm)
(66cm)
6", 125# ASA Flanges
26"
24"
38"
(61cm)
(40cm)
(97cm)
15.6"
0
330
300
270
240
210
180
150
120
90
60
30
30
60
90
U.S.G.P.M.
Cu.Mtr./Hr.
Feet Meters
100
CAPACITY
TOTAL HEAD
A
B
C
2700 2400 2100 1800 1200 1500 900 600 300
600 500 400 300 200
HYDRAULIC INPUT:
A) 53 GPM
Typical Performance with
HT100 Power Unit
B) 70 GPM
Typical Performance with
HT150 Power Unit
C) 90 GPM
Typical Performance with
HT200 Power Unit
