Hydra-Tech S1.5A User Manual
Page 2
Model S1.5A Overall Dimensions
S1.5A Typical Performance
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
:
Curves are based on pumping water at 60°F. For performance curves other than shown above, consult factory.
HYDRAULIC INPUT:
(A)* 4.5 GPM @ 500-750 PSI
(B)** 6.5 - 6.9 GPM @ 1100-1450 PSI
*Typical performance with
HT6 Power Unit
**Typical performance with
HT13 Power Unit
0
165
150
135
120
105
90
75
60
45
30
15
15
30
45
U.S.G.P.M.
Liters/Minute
Feet
Meters
90
CAPACITY
TOTAL HEAD
150
135
120
105
90
75
60
45
30
15
540
450
360
270
180
13 1/2"
(34 cm)
(39 cm)
15 1/2"
1-1/2"-9 NHT
Male thread
Top View
Return
Press.
1 1/2" NPT(F) Discharge
3/8" NPT(F)
Hydraulic
Connections
5 5/16"
(14 cm)
