Hydra-Tech S310 - Manual (Page 2)

Model S310 Overall Dimensions
S310 Typical Performance
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
: www.hydra-tech.com E-Mail : [email protected]
Curves are based on pumping water at 60°F. For performance curves other than shown above, consult factory.
13 1/2"
3 1/8"
(79 mm)
(343 mm)
TOP VIEW
Pressure Port
1/4" NPT (F)
Return Port
1/4" NPT (F)
1 1/4 " NPT(F)
DischargePort
0 5 10 15 20 25 30 35 40 45 50 55 60 65
135
120
105
90
75
60
30
15
20
50
U.S.G.P.M.
Liters/Minute
F
e
et
M
e
te
rs
50 100 150 200 250
T
O
T
A
L
H
E
A
D
A
B
C
45
150
165
180
195
10
30
40
60
HYDRAULIC INPUT:
A) 3 GPM @ 500 - 800 PSI
B) 4 GPM @ 600 - 1100 PSI
C) 5 GPM @ 800 - 1350 PSI
D) 6 GPM @ 950 - 1800 PSI
D
