Hydra-Tech S2C - Manual (Page 2)

Model S2C Overall Dimensions
S2C Typical Performance
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
: www.hydra-tech.com E-Mail : [email protected]
Curves are based on pumping water at 60°F. For performance curves other than shown above, consult factory.
9 3/8" (24 cm)
9 3/4" (25 cm)
6 3/4" (17 cm)
2" NPT (Female) Discharge 3/8" SAE or JIC Motor Ports
0
55
50
45
40
35
30
25
20
15
10
5
5
10
15
U.S.G.P.M.
Liters/Minute
Feet Meters
CAPACITY
TOTAL HEAD
100 90 80 70 60 50 40 30 20 10
67 200 133 266 333 360
60
65 20
Hydraulic Input:
1.2 GPM @ 2000-2200 PSI
(5 LPM @ 136-150 BAR)
