13.8 PULSE OUTPUT functional class
The PULSE OUTPUT functional class is comprised of the functions regarding the pulse output.
PULSE OUTPUT
PULSE OUTPUT
Pulse or frequency
output
Pulse or frequency
output
Pulse output unit
Pulse output unit
PULSE OUTPUT
functional class
Output of
[Pulses]
_______________
Pulses
Frequncy
Accumulation of
1.0 kg
______________
g
kg
t
m³
l
USG
UKG
USB
lbs
ston
lton
ft³
acft
Pulse value
Pulse value
1 pulse per
[1.0] unit
________________
0.001
0.01
0.1
1.0
10.0
100.0
Pulse width
Pulse width
Pulse width
0050.0 ms
13.8.1 Pulse or frequency output
The Pulse or frequency output function allows the operator to define whether pulses represent a unit of
flow, i.e lbs, kg, USG, for totalizing or a frequency between 0 and 1 kHz that represents an analog output
over the measuring range.
