12.3 Operating modes
The CT can be operated in the following modes:
1. Display mode:
In display mode, measured values can be displayed in various
combinations and CT settings can also be displayed. Parameter
settings cannot be changed in this mode. Display mode is the
standard (default) operating mode when the device is switched on.
2. Programming mode:
In programming mode, CT parameters can be redefined. After
entering the correct password, changes that are permissible for the
customer (customer password) or all functions (service password
for technicians) can be realized.
12.4 Operation
12.4.1 Operator interface
Functional classes are displayed as
headings beneath which displays and
parameters are shown in logical
groups.
Functional class
Functional class
Function with
numerical Input
Function with
numerical Input
Display
Display
Legend
Numerical Input
153.40
Function
value selected from
list
Function
value selected from
list
Selection
[no]
___________
no
yes
Parameter level
Headline
Main menu
Menu level subpoint
Functionial class
Functionial class
Beneath this is the menu level, which
lists all measured value displays or
the headings for their underlying pa-
rameters (parameter level).
All functional classes are interlinked
horizontally, while all subpoints that
are assigned to a functional class are
displayed beneath the relevant class.
