13.5 FLOW functional class
The FLOW functional class is comprised of functions that affect lower- and upper-range values and the
processing of the measured flow rates. In Programming mode (see 12.3 Operating modes), i.e. after a
password has been entered (see 12.4.3.3 Passwords, 13.2 PASSWORD functional class), the operator
can change the settings regarding flow.
FLOW
FLOW
Mass flow QM unit
Mass flow QM unit
mass flow
QM range
mass flow
QM range
FLOW
functional class
Mass flow in
[kg/h]
_________________
kg / s
kg / min
kg / h
t / h
g / min
lbs / s
lbs /min
lbs / h
shton / h
lton / h
QM Range = 100%
00120.00 kg/h
Mass flow
QM limit MIN
Mass flow
QM limit MIN
Mass flow limit
MIN = 10 %
Mass flow
QM limit MAX
Mass flow
QM limit MAX
Mass flow limit
MAX = 90 %
Mass flow limit
hysteresis
Mass flow limit
hysteresis
Mass flow limit
hysteresis 01 %
Volume flow unit
QV
Volume flow unit
QV
Volume flow in
[l / h]
________________
m³ / h
l / h
l / min
l / s
USG / h
USG / min
USG / s
UKG / h
UKG / min
UKG / s
USB / d
MG / d
m³ / s
ft³ / min
acft / s
Volume flow
QV range
Volume flow
QV range
QV Range = 100 %
0120.00 l/h
To change the current settings, enter the customer password. Otherwise, the settings can only be dis-
played but not changed. To cancel the current action, press Esc.
