275
2. Click the Archive button (2).
3. The archive navigation panel is then displayed, with the following interface features:
a. Timeline (3). Archive navigation via the timeline in the web client is the same as when
working in the EyStream client (see Navigating Using the Timeline ).
b. Playback control panel (4). Archive navigation via the playback panel in the web client
is the same as when working in the EyStream client (see Navigating Using the
Playback Panel ).
c. Archive position selection panel. The archive position selection panel is opened by
left-clicking the date above the timeline (see Navigating Using the Archive Position
Selection Panel ).
Archive position selection panel for the web client
To choose a time position in the archive by using the archive position selection panel:
1. Click the date above the timeline to open the position selection panel (1).
