213
5. Playback panel
6. Time indicator
You can also navigate through the archive by easily flipping through recordings.
Navigating Using the Timeline
Note
Use of the timeline is described in detail in the section
The Timeline .
You can select recordings in the archive for playback in a viewing tile by using the timeline, in one
of two ways:
1. Left-click the indicator (1) and drag it to the corresponding position on the timeline.
Alternatively, you can left-click the left portion of the timeline.
Note
The position on the timeline is a graphical representation of a specific
moment in time.
The frame corresponding to the selected position (moment in time) will then be displayed in
the viewing tile (2).
2. Click the indicator and specify the date and time to which you want to navigate in the
archive, in DD/MM/YY HH:MM:SS format.
You are then taken to the specified point in the archive.
If one video camera is in archive mode and you move the indicator to a point for which there is no
video, the indicator will automatically go to the video for the closest point in time. If two or more
video cameras are in archive mode, you will not be taken to the video for the closest point in
time; the message No archive will be shown on screen.
