5
Changing Protocol Information
En
gl
is
h
3. CHANGING PROTOCOL INFORMATION
The DIP switches on the bottom of the camera control 3 values:
1. The ID of the camera, which allows the DVR/keyboard controller to
identify different PTZ cameras.
2. The protocol, which is the language that allows the camera and DVR/
keyboard controller to speak to each other (e.g. Pelco D).
3. The baud rate, which is the frequency of communications.
The illustration below shows the default values of the DIP switches.
Default ID: 1
Default Baud Rate: 2400
Default Protocol: Pelco-D
