28 06-TTM-UM-00158 8/2012
TFXL ERROR CODES
Revised 5-25-2009
Code Number Description Correction
Warnings
0010
Signal Strength is below Signal Strength
Cutoff entry
Low signal strength is typically caused by one of the
following:
» Empty pipe
» Improper programming/incorrect values
» Improper transducer spacing
» Non-homogeneous pipe wall
0011
Measured Speed of Sound in the liquid is
greater than ±10% diff erent than the value
entered during meter setup Verify that the correct liquid was selected
in the BASIC menu.
Verify that pipe size parameters are correct.
Class C Errors
1001 System tables have changed
Initiate a meter RESET by cycling power or by selecting
SYSTEM RESET in the SEC MENU.
1002 System confi guration has changed
Initiate a meter RESET by cycling power or by selecting
SYSTEM RESET in the SEC MENU.
Class B Errors
3001 Invalid hardware confi guration Upload corrected fi le.
3002 Invalid system confi guration Upload corrected fi le.
3003 Invalid strategy fi le Upload corrected fi le.
3004 Invalid calibration data Re-calibrate the system.
3005 Invalid speed of sound calibration data Upload new data.
3006 Bad system tables Upload new table data.
Class A Errors
4001 Flash memory full Return unit to factory for evaluation
TABLE A-5.1 - TFXL ERROR CODES
