Draw-Tite 59508 BIKE CARRIER - NV2 - HITCH MOUNT User Manual
Page 7
Product Code:
59508
Product Name:
NV2
www.rolaproducts.com
www.rola.com.au
59508N Rev F 01/12
Cequent Performance Products - Plymouth, MI. USA.
Technical Service: (888) 521-0510
Cequent , a division of TriMas Corporation Pty Ltd.
20-50 Waterview Close, Dandenong South, VIC, Australia 3175
Ph:1300 888 051
PRINTED IN CHINA
Lea atentamente todas las instrucciones antes de armar, instalar y/o usar este producto.
.
Bases
Bases
Tubo de apoyo
Tubo de apoyo
Tapa del tubo
Observe la
orientación de la base
PARE
Ensamble de la base al tubo de apoyo:
Ensamble (4) bases y las (2) tapas de los tubos en los tubos de apoyo como se muestra en el diagrama 3.
OBSERVE el ángulo de orientación de las bases como se muestra en el diagrama 4
Diagrama 4
Diagrama 3
