Draw-Tite 59508 BIKE CARRIER - NV2 - HITCH MOUNT User Manual
Page 12
Product Code:
59508
Product Name:
NV2
www.rolaproducts.com
www.rola.com.au
59508N Rev F 01/12
Cequent Performance Products - Plymouth, MI. USA.
Technical Service: (888) 521-0510
Cequent , a division of TriMas Corporation Pty Ltd.
20-50 Waterview Close, Dandenong South, VIC, Australia 3175
Ph:1300 888 051
PRINTED IN CHINA
Veuillez lire toutes les instructions attentivement avant le montage, l’installation et/ou l’usage de ce produit.
Berceau
Berceau
Tubes-supports
Tubes-supports
Capuchon de tube
Noter l’orientation
des berceaux
STOP
Montage du berceau sur le tube-support :
Assemblez quatre (4) berceaux et deux (2) capuchons de tube sur les tubes-supports, comme illustré sur le
diagramme #3. REMARQUE
Orientez l’angle des berceaux, comme illustré sur le diagramme #4.
Diagramme 4
Diagramme 3
