INTRODUCTION
1-1. THE STE100 OPERATING MODE
Before you start setting up your
STE100
for the first time, be sure you know what you actually want to do with it.
The
STE100
offers one operating mode, which results in a versatile video production tool for live event staging
and fixed installation applications.
* NOTE *: We recommend resetting the device to its default values every time you set up your shows or events
(see the “Operating The STE100” chapter, p23).
1-2. USEFUL TERMS AND DEFINITIONS
LAYER:
a “Layer” is an image display element (such as a Key) that has an associated visual priority — either
in front of background Live.
The
STE100
can simultaneously view no less than 2 layers (1 background Live and 1 layer like a key or 2 PIP
on a background color).
KEYING:
a “Key” is an electronic process whereby an image is electronically superimposed over another
source or background, by cutting out either a color (Chroma Key), or its brightness or luminance levels (Luma
Key). Keys are typically used for titles, logos and special effects.
STE100
allows to use a live source with
green or blue background and to key it over any other live input.
This mode allows for a single
STE100
to seamlessly switch and blend any of its 10 analog/digital inputs with
any other of the inputs. The Edge Blending Mode is the
STE100
native mode, and has no less than 2 layers.
Edge Blending Mode
