The

STE100

allows the creation of user defined presets very easily. Any setup you have configured on

screen, can be stored into one of the 4 available user presets.

1. After having configured Layers, PIP transitions, logos... on your screen (see Working with the

STE100

p.27), go to the Preset menu by pressing the

[EXIT/MENU]

button, and select Preset by rotating the scroll

knob. Then, press the

[ENTER]

button to enter the Preset sub-menu. Choose Preset Copy by scrolling

with the corresponding knob, and press the

[ENTER]

button to access the sub-menu.

2. In the sub-menu, choose Save From Main or Save From Preview to determine which screen you want to

memorize the preset from, then set the preset memory (#1 to #4) you wish to use as your “User Preset”

(by default, the

STE100

will choose the next available preset in the

STE100

memory).

3. By pressing the

[ENTER]

button, the

STE100

will ask you to confirm. Select Yes, your screen is

memorized as a preset.

The four user presets of the

STE100

can be called back at any stage during your show or event.

1. Press the

[PRESET]

button, then press one of the four first Input Selection section buttons to choose which

memory (#1 to #4) you wish to use. The preset will be loaded to your preview preset.

2. Once you have selected your preset, simply press the

[TAKE]

button to view the result on your main

screen.

The

STE100

allows to work with up to 10 stereo inputs, 1 auxiliary input, and 2 embedded SDI audio inputs

(via the SDI BNC connectors), all accessible via the Audio menu of the

STE100

, and which can be affected

to one or both of the 2 independant balanced/unbalanced outputs of the device.

Creating Presets

Working with Presets

Working with Audio
