4-3. WORKING WITH THE STE100
It is strongly recommended resetting all of the default values of your
STE100
unit before setting up your
shows and events. To do so, press the
[EXIT/MENU]
button and select Control in the menu by rotating the
corresponding knob. Then press the
[ENTER]
button to enter the Control sub-menu. Select Default Values
by rotating the scroll knob, and press the
[ENTER]
button to enter your choice to restart your
STE100
with its
factory settings. This operation should take approximately 30 seconds.
Analog Way
engineers have developed a handy, user friendly way of identifying machine status on the front
panel, via the use of color codes on the buttons of the machine. All new
Analog Way
machines use the same
codes, for quick recognition of the status of any device of the range, at any given time.
For the
STE100
, button color codes are as follow:
- Sources on the Main output are indicated in
red
when active,
- Sources on the Preview output are indicated in
green
when active,
- Buttons in the layer section turn
red
or
green
, depending on whether the selected layer is active in
respectively the Main or Preview preset,
- Menu buttons are indicated in
green
,
- Selecting a button with an available source or function will cause that button to blink
green
or
red
once it is
on the program,
-
[TAKE]
button reacts as follows:
• If take function is available, the button will appear in
green
.
• When the take function is active, it will light up
red
.
1. In the MENU section, press the
[EXIT/MENU]
button and select Input in the menu by rotating the scroll knob.
Then press the
[ENTER]
button to enter the Input sub-menu.
2. In the Input menu, select the type of input you have plugged into the
STE100
by rotating the scroll knob
(see Input Specifications, p.11). Then press the
[ENTER]
button to enter the types of inputs connected to
the
STE100
.
3. Press the
[EXIT/MENU]
button to return to the main menu.
4. Repeat steps #1 to #3 for every source connected to your
STE100
.
Reseting default values
STE100 color codes
Input selection settings
Solid red:
Blinking red:
Solid green:
Blinking green:
#1 = Source, Layer or Window is on Main
#2 = Freeze enable
#1 = Source or Layer is on Preview
#2 = Function available for modification
Active Layer or Source for modification on Main
Active Layer or Source for modification on Preview
