Analog Way Smart Edge User Manual

Page 37

To help you calculate the correct screen/picture ratio, Analog Way

offer free software to faciltate the calculation of key parameters.

By entering basic information, such as your projector matrix size

and your image size, you can automatically obtain all the essential

variables (Projector image size, distance between projectors, etc.)

to make your Soft Edge. It is also recommended to use a Hi-Res

DVI computer source for this background.

The Soft Edge Blended presentation will be much more impressive

with contrasted images and saturated colors.

Soft Edge Blending presentations will offer you the opportunity

to change the overall look of a space in a few minutes. With the

flexibility of displaying multiple sources of video, with the option

of merging the image into one, the impact of your services and

presentations is increased exponentially.

The

STE100

offers a wide variety of transitions between the scenes you create for your shows and events. It

allows for live recall of 4 user presets, each of which you can edit at any given time.

1. Whether catering for complex event setups, or putting together intricate shows, your

STE100

will

also deliver some of what you could expect from a dedicated mixer, along with its switcher and scaler

capabilities.

2. In the Layer Menu, make the position, size, border and transparency settings you like, then select

Opening Effect in the layer options, press the

[ENTER]

button and select Type. Select Slide Left - Right

for example, and press the

[ENTER]

button to confirm. Navigate to Duration in the Opening Effect

sub-menu, and set the duration of your effect by rotating the

[SCROLL]

knob and pressing

[ENTER]

Repeat the procedure in the Closing Effect sub-menu to determine the way your layer will close. Try Slide

From Left - Right for the closing type with a duration of 1.5 seconds for example.

The smooth Move function manages a different time between the opening and closing transition. The movement

is both fast and slow. The function is enabled or disabled in Menu Layer.

Transitions & effects

Smooth Move
