Analog Way Smart Edge FX User Manual
Page 6
4
INTRODUCTION
1-1. THE STE200 OPERATING MODE
Before you start setting up your
STE200
for the first time, be sure you know what you actually want to do with it.
The
STE200
offers one operating mode, which results in a versatile video production tool for live event staging
and fixed installation applications.
* NOTE *: We recommend resetting the device to its default values every time you set up your shows or events
(see the “Operating The STE200” chapter, p26).
1-2. USEFUL TERMS AND DEFINITIONS
LAYER:
a “Layer” is an image display element (such as a Key) that has an associated visual priority — either
in front of background Live.
The
STE200
can simultaneously view no less than 4 layers (1 background Live and 1 layer like a key or 2 PIPs
on a background frame + 1 logo).
KEYING:
a “Key” is an electronic process whereby an image is electronically superimposed over another
source or background, by cutting out either a color (Chroma Key), or its brightness or luminance levels (Luma
Key). Keys are typically used for titles, logos and special effects.
STE200
allows to use a live source with
green or blue background and to key it over any other live input.
This mode allows for a single
STE200
to seamlessly switch and blend any of its 12 analog/digital inputs with
any other of the inputs. The Edge Blending Mode is the
STE200
native mode, and with no less than 4 layers
(1 background Live + 1PIP + 1 logo + 1 background frame).
Edge Blending Mode
