CD RESPONSE COMMAND DESCRIPTION

TYPE

VALUE

MIN

MAX

DESCRIPTION

STATUS COMMANDS
UN

UN

Measures unity in tens of kHz.

Rd

0

65535

ex : 14500 = 145 MHz

IL

IL

Horizontal period of input signal (M)

Rd

0

65535

Line frequency (in kHz) = (UN VALUE)x10 ÷ (IL VALUE).

il

il

Horizontal period of input signal (P)

Rd

0

65535

Line frequency (in kHz) = (UN VALUE)x10 ÷ (il VALUE).

ID

ID

Vertical period of input signal (M)

Rd

0

65535

Frame frequency (in Hz) = (Line frequency in Hz) ÷ (ID VALUE).

id

id

Vertical period of input signal (P)

Rd

0

65535

Frame frequency (in Hz) = (Line frequency in Hz) ÷ (id VALUE).

IP

IP

Input Sync. detection (M).

Rd

0

1

0 = no Sync. detected

1 = Sync. detected.

ip

ip

Input Sync. detection (P).

Rd

0

1

0 = no Sync. detected

1 = Sync. detected.

IH

IH

Sign of the horizontal input Sync. (M) Rd

0

1

0 = negative

1 = positive.

ih

ih

Sign of the horizontal input Sync. (P)

Rd

0

1

0 = negative

1 = positive.

IV

IV

Sign of the vertical input Sync. (M)

Rd

0

1

0 = negative

1 = positive.

iv

iv

Sign of the vertical input Sync. (P)

Rd

0

1

0 = negative

1 = positive.

0 = Separate H &V sync.

IK

IK

Input Sync type detection (M).

Rd

0

3

1 = Composite sync. (TTL).

ik

ik

Input Sync type detection (P).

Rd

0

3

2 = SOG (Sync. On Green).

3

=

Composite

sync.

(analog).


II

II

Interlaced signal detection (M).

Rd

0

1

0 = not interlaced

1 = interlaced.

ii

ii

Interlaced signal detection (P).

Rd

0

1

0 = not interlaced

1 = interlaced.

IO

IO

"Out of range" signal detection (M).

Rd

0

1

0 = In range

1 = Out of range.

io

io

"Out of range" signal detection (P).

Rd

0

1

0 = In range

1 = Out of range.

0 = no signal

1 = wrong signal

2 = NTSC std (3.58/60)

3 = PAL std (4.43/50)

4 = SECAM (50Hz)

5 = B&W (50Hz)

6 = B&W (60Hz)

7 = YUV 50Hz

8 = YUV 60Hz

9 = RGB 50Hz

10 = RGB 60Hz

11 = 640x480

IF

IF

Standard input signal detection (M).

Rd

0

35

12 = 800x600

13 = 1024x768

14 = 1280x1024

15 = 1400x1050

16 = 1600x1200

17 = 852x480

if

if

Standard input signal detection (P).

Rd

0

35

18 = 1280x720

19 = 1280x768

20 = 1366x768

21 = 1680x1050

22 = 1920x1080

23 = 1080i 50

24 = 1080i60

25 = 720p 50

26 = 720p 60

26 = 1080p 24

28 = 1080p 25

29 = 1080p 30

30 = 1080p 50

31 = 1080p 60

32 = 1080sf 24

33 = 480p 50

34 = 480p 60

35 = 480p 72

XA

XA

Synchronized input.

Rd

0

8

Identical as XR command.

XF

XF

Synchronized input standard (M).

Rd

0

29

Identical as IF command.

XT

REFT

Frame frequency of the synchro-

nized input (M).

Rd

0

65535

Value in hundredth of Hz.

OTHERS COMMANDS
TP

TP

T-BAR position.

Rd/Wr

0

255

TB

TB

Executed percentage of the effect.

Rd

0

65535

0 = 0%

65535 = 100%

?

DEV

Device type.

Rd

0

65535

#

#1,....#0 Send all device parameters.

Rd

NOTE : (M) = MAIN output.

Rd/Wr = Read and write command. (P) = PREVIEW output.

Rd = Read only command.
