8-2. DISPLAY OUTPUTS
8-3. AUDIO INPUTS
8-4. MAIN AUDIO OUTPUT
8-5. PRELIST AUDIO OUTPUT
• MAIN ANALOG
Connectors : HD15 and DVI-I (2x buffered).
Resolution : 4/3 & 5/4 : 800x600, 1024x768, 1280x1024, 1400x1050, 1600x1200.
16/9 & 16/10 : 852x480, 1280x720, 1280x768, 1366x768, 1920x1080.
Frame frequency : 50, 60, 72***, 75*** Hz and follow (*** = not available for all resolutions).
Sync. types : RGBHV, RGB/S, RGsB (Sync On Green).
Levels : R, G, B = 0.7 Vp/p.
H & V Sync = TTL
Composite Sync = TTL and 0.3 V.
SOG (Sync On Green) = 0.3 V.
Impedance : R, G, B = 75 ohms.
• MAIN DIGITAL
Connector : DVI-I.
Format : Digital Visual Interface (DVI). TMDS Single link.
Resolution : Up to 1600 x 1200 @ 60 Hz.
• PREVIEW
Connectors : HD15.
Format : XGA / 60 Hz.
Sync. types : RGBHV.
Levels : R, G, B = 0.7 Vp/p.
H & V Sync = TTL
Impedance : R, G, B = 75 ohms.
Connectors : Jack 3.5 mm (inputs #1, 2 & 8) and MCO (inputs #3, 4, 5, 6, 7 & AUX).
Type : Stereo balanced (inputs 7 & AUX) & unbalanced.
Levels : Vi = + 18 dBu (max).
Zi = 20 kΩ unbalanced.
Zi = 40 kΩ balanced.
Gain : Adjustable.
Connectors : MCO.
Type : Stereo balanced & unbalanced.
Levels : Vo = + 18 dBu max (unbalanced).
Zo = 300 Ω (unbalanced).
Vo = + 24 dBu max (balanced).
Zo = 600 Ω (balanced).
Gain : 0 dB nominal (adjustable with Master volume).
Connectors : Jack 3.5 mm.
Type : Unbalanced.
Levels : Vo = + 18 dBu max.
Zo = 300 Ω.
Gain : 0 dB nominal (adjustable with Master volume).
