MAC address : The MAC address, also referred to hardware address, is a unique number assigned to each device.
The MAC address is available on the bottom device label.
9-6
[key locking]
+ ENTER.
Select an item with ◄► and change the mode with ENTER.
• [
All
] : Locks/unlocks all the front panel switches.
• [
Menus
] : Locks/unlocks the LCD CONTROL switches.
• [
autolock
] : Allows selecting an input only if a signal is connected.
• [
Input
] : Locks/unlocks the INPUT SELECTION and FREEZE switches.
NOTE : To unlock press simultaneously ENTER and EXIT.
9-7 [Stand-by]
+ ENTER.
9-7-1 [
Baud rate
] + ENTER.
Select the baud rate of the display device with ◄► +
ENTER (9600, 2400 & 1200).
9-7-2 [
Message ON
] + ENTER.
This function allows to store the ON message of your display device. Whenever your device goes out of stand-
by mode it will send the stored message to your display device. The ON message can be composed of up to 50
bytes. For each byte, select the required ASCII code with ◄► and validate with ENTER.
NOTE : The 0 value allows to display : no data.
9-7-3 [
Message OFF
] + ENTER.
This function allows to store the OFF message of your display device. Whenever your device goes out of stand-
by mode it will send the stored message to your display device. The OFF message can be composed of up to
50 bytes. For each byte, select the needed ASCII code with ◄►, then press ENTER.
NOTE : The 0 value allows to display: no data.
9-7-4 [
Reset mess ON
] + ENTER.
Allows to reset the ON message.
9-7-5 [
Reset mess OFF
] + ENTER.
Allows to reset the OFF message.
9-7-6 [
Stand by time
] + ENTER.
When the device doesn't detect any signal on the selected input, it sets itself to STANDBY mode after the dura-
tion of your choice. Select a duration with ◄► +
ENTER.
NOTE : Select OFF to inactivate this function.
9-7-7 [
Stand by
] + ENTER.
Allows to set the device to STANDBY mode. To get out of STANDBY mode, press one of the front panel buttons.
9-8
[Erase memories]
+ ENTER.
This function allows erasing all NON-volatile image memories. Select [
YES
] and validate with ENTER.
9-9
[Default value]
+ ENTER.
This function allows setting the following functions to the factory settings. Select [
YES
] and validate with ENTER.
FUNCTION POSITION
input type
Computer HV/C.
used input
All used.
H sync load
All Hi-Z.
VCR mode
All off
output format
SXGA 60Hz 4/3.
Output sync
H&V.
type of screen
4/3
test
pattern
no
switching
seamless
#1
pos. settings
0
aspect ratio in
4/3
aspect ratio out
1:1
brightness
128
black
level
128
contrast
128
color
128
hue
128
under/overscan
overscan
sharpness
3
master volume
192
audio source
auto follow
audio
level
48
audio balance
32
auxiliary input
OFF
mute
OFF
display logo
all ON
assignment
all
none
key locking
all unlock
fade color
R, G, B = 0
RS232/LAN port
RS232
