5-5. FUNCTIONS DESCRIPTION
1► [SWITCHING] + ENTER.
1-1 [ Fast switching ] + ENTER.
Select an item with ◄► + ENTER.
• [ Internal rate ] : The output frame rate is 60 Hz or 75 Hz depending of the selected output format. A higher frame
frequency gives a better visual aspect when displaying static pictures.
• [ Follow # x ] : The output frame rate is identical to the selected input Frame Rate : 50 Hz if the input video
standard is PAL or SECAM and 59.94 Hz if the input video standard is NTSC. This function
allows improving the motion pictures.
1-2 [ Seamless ] + ENTER.
Select the computer input used as reference with ◄► + ENTER.
• [ Seamless #1 ] : The device is in Seamless mode. The output format & rate are the same as computer #1.
• [ Seamless #8 ] : The device is in Seamless mode. The output format & rate are the same as computer #8.
2► [INPUT] + ENTER.
2-1 [ Auto settings ] + ENTER.
This function detects automatically the input type of each source connected to the inputs.
2-2 [ Input status ] + ENTER.
Indicates the status of the selected input.
2-3 [ Input type ] + ENTER.
① Select an input with ◄► + ENTER.
② Select the input signal type with ◄► + ENTER between :
• [ SDTV Composite] • [ SDTV RGB SOG]
• [ SDTV S.VIDEO] • [ SDTV RGBS ana.]
• [ SDTV YUV] • [ Computer SOG]
• [ SDTV RGBS TTL] • [ Computer HV/C]
• [ Computer DVI]
• [ HDTV] : HDTV input format (720p, 1035i and 1080i).
• [ Audio only] : Select this function if you only want to connect an audio source (no video signal needed).
③ Then for [ SDTV Composite] and [SDTV S.VIDEO], select the video standard with ◄► + ENTER between :
• [ NTSC / PAL / SECAM ] : automatic NTSC, PAL, and SECAM standard detection.
• [ NTSC ] : NTSC standard detection only. • [ PAL ] : PAL standard detection only.
• [ NTSC 4.43 60 Hz ] : NTSC 4.43 60Hz detection. • [ PAL 4.43 60Hz ] : PAL 4.43 60Hz detection.
• [ SECAM ] : SECAM standard detection only. • [ B & W 50/60 Hz ] : Black and White detection.
2-4 [ used input ] + ENTER.
Select an input and then select an item ◄► + ENTER between :
• [ used ] : A signal is connected to the input.
• [ unused ] : No signal is connected to the input. The input is unused.
2-5 [ H sync load ] + ENTER.
Select for each input the load of the H Sync. with ◄► + ENTER.
2-6 [ VCR mode ] + ENTER.
This function allows improving the image contour of low quality VHS tapes. Select [on] with ENTER.
2-7 [ VIS ] + ENTER.
This function allows defining the sources which are synchronized together (external genlock). The synchroni-
zed sources can be seamlessly switched between themselves during an effect (into a PIP for example). This
switching mode is called VIS (Vertical Interval Switching).
