3
4
L
R
L
R
UNBALANCED
LEFT
LEFT
RIGHT
RIGHT
GROUND(S)
Input #3
Input #4
2) MCO male connector
Input #3 to 7 & AUX are equipped with this connector. Connect your audio sources as follow :
- Input #3, 4, 5, & 6 : unbalanced connection only.
- Inputs
#7 & AUX : balanced & unbalanced connection.
L+
L-
R+
R-
UNBALANCED
LEFT
RIGHT
GROUND
7
3
4
L+
L-
R+
R-
BALANCED
L+
R+
L-
R-
GROUND(S)
7
2-7. AUDIO OUTPUT
You can connect an unbalanced stereo audio device to the 3.5 mm jack connector (for audio control).
The audio output is equipped with a 5-pin MCO male connector. This connector allows connecting BALANCED or
UNBALANCED audio systems.
L+
L-
R+
R-
UNBALANCED
LEFT
RIGHT
GROUND
OUT
L+
L-
R+
R-
BALANCED
L+
R+
L-
R-
GROUND(S)
OUT
2-6. PRELIST AUDIO
