ClimaCool IOM AR2 SERIES - Manual (Page 61)

59
www.climacoolcorp.com
®
Heat Exchanger
Refrigerant Circuit #1
Refrigerant Circuit #2
Isolation Ball Valve (2”)
Service Port (3/4”)
Isolation Ball Valve (2”)
Service Port (3/4”)
From Cooling Tower
To Cooling Tower
Header
Header
To Drain
Heat Exchanger
Refrigerant Circuit #1
Refrigerant Circuit #2
Isolation Ball Valve (2”)
Service Port (3/4”)
Isolation Ball Valve (2”)
Service Port (3/4”)
From Cooling Tower
To Cooling Tower
Header
Header
Cleaning Pump
Cleaning Tank
Fig. 1
City Water
Cleaning Arrangement.
Fig. 2
In Place
Cleaning Arrangement.
Heat Exchangers
