Start Up and Warranty Registration Form
Start-Up (Air-Cooled)0308 .doc
Project Name: _________________________________ Start-Up Date: __________________
Address: ____________________________________________________________________
Module #: _______________ Model #: _________________
Serial Number: _______________________
Chiller # ________ Bank # _________ On-Site Location: ____________________________________
Evaporator 6” Main Inlet Pressure _______ Evaporator 6” Main Outlet Pressure _______ delta P_______
Evaporator “flow device” shut off chiller below approx. 40% loss of flow _________
Water Sample taken (Mark “X”) Evaporator ___
Water sample bottles are provided. Follow instructions on label and mail same day sample is taken, if possible.
All wiring terminations in module panel, safeties and compressors tightened
_____
Voltage / Ground
L1 ________ L2 ________
L3 ________
Phase / Phase
L1/ L2 ________
L2/ L3 ________
L1/ L3 ________
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Circuit # 1
Refrigerant Type: (circle one) R-22 R-407C Field Charge (lbs)_________
Amperage
L1 ________ L2 ________ L3 ________
_
_
_
_
_
_
_
_
l
e
v
e
L
l
i
O
s
s
al
G
t
h
g
i
S
Comments: __________________________
Suction Pressure (PSIG)
________
____________________________________
Suction Temperature (°F)
________
____________________________________
Discharge Pressure (PSIG)
________
____________________________________
Discharge Temperature (°F)
________
____________________________________
Compressor Superheat (°F)
________
____________________________________
Evaporator Entering Water Temperature (°F) ________
____________________________________
Evaporator Leaving Water Temperature (°F)
________
____________________________________
Condenser Entering Air Temperature (°F)
________
____________________________________
Condenser Leaving Air Temperature (°F)
________
____________________________________
Condenser Entering Refrig. Liquid Temp (°F) ________
____________________________________
Condenser Liquid Subcooling Temperature (°F) ________
____________________________________
Evaporator Pressure Differential (PSIG)
________
____________________________________
Verify Safety Settings:
Low Limit_____ High Pressure Limit_____ Low Pressure Limit_____
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Circuit # 2
Refrigerant Type: (circle one) R-22 R-407C Field Charge (lbs)_________
Amperage
L1 ________ L2 ________ L3 ________
_
_
_
_
_
_
_
_
l
e
v
e
L
l
i
O
s
s
al
G
t
h
g
i
S
Comments: __________________________
Suction Pressure (PSIG)
________
____________________________________
Suction Temperature (°F)
________
____________________________________
Discharge Pressure (PSIG)
________
____________________________________
Discharge Temperature (°F)
________
____________________________________
Compressor Superheat (°F)
________
____________________________________
Evaporator Entering Water Temperature (°F) ________
____________________________________
Evaporator Leaving Water Temperature (°F)
________
____________________________________
Condenser Entering Air Temperature (°F)
________
____________________________________
Condenser Leaving Air Temperature (°F)
________
____________________________________
Condenser Entering Refrig. Liquid Temp (°F) ________
____________________________________
Condenser Liquid Subcooling Temperature (°F) ________
____________________________________
Evaporator Pressure Differential (PSIG)
________
____________________________________
Verify Safety Settings:
Low Limit______ High Pressure Limit______ Low Pressure Limit______
NOTE: Correct rotation of scroll compressors is extremely critical. Incorrect rotation could damage the compressor.
___________________________
Contractor Name:
___________________________
__________________________________
Address:
___________________________
(Authorized Signature)
Phone:
___________________________
Date: _____________________________
Start-Up and Warranty Registration Form
(Air-Cooled)
Sign & date and fax: (405) 745-2072 Attn.: Technical Services
Or E-mail:
®
