ClimaCool Hydronic Refrigeration
The ClimaCool Modular Chiller -
Hydronic Configuration
Figure 1 - Chilled Water Circuit
NOTE: Figures 1 depicts hydronic piping in each ClimaCool chiller module .
Heat Exchanger
Refrigerant Circuit #1
Refrigerant Circuit #2
Service Port (3/4”)
Pete’s Port
Service Port (3/4”)
Chilled Water Outlet
Chilled Water Inlet
Sensor Well (internal)
Cap Tube to Low Limit
Protection Thermostat
Header
Header
Isolation Ball Valve (2 or 2-1/2”)
Isolation Ball Valve (2 or 2-1/2”)
Pete’s Port
