I 0201 GB - 18
5.5.2 - “SPLIT” CONTROL
The SPLIT function is only possible in the case of static unbalance or ALU-S on the outside. It serves for
concealing any stick-on unbalance correction weights behind the rim spokes.
TO PRESET THE NUMBER OF RIM SPOKES
-From the STATIC or ALU-S measurement screen, press
6
;
- A window appears on the display indicating the currently preset number of spokes.
- Set the required number of spokes in the range 3 to 12 by pressing 1 and 2
- press to confi rm the presetting.
- Bring a spoke to the 12 o’clock position.
- press ; the Measurement Screen reappears with the unbalance values already split.
The ALU-S unbalance on the inside does not vary while as regards the STATIC unbalance and that
ALU-S on the outside:
- Gradually turn the wheel until an unbalance value appears.
- Apply an adhesive weight of the value indicated on the screen for the outside or STATIC, behind
the spoke in the 12 o’clock position.
- Again turn the wheel until a new unbalance value appears.
- Apply an adhesive weight of the value indicated on the screen for the outside or STATIC, behind
the spoke in the 12 o’clock position.
- Perform a spin to check for correct wheel balancing.
N.B. When SPLIT is enabled, the icon appears to the left of the screen.
